VeriFlow-CC

Claude Code-driven RTL design pipeline — zero Python dependencies, Claude Code main session is the driver.

What It Is

VeriFlow-CC treats Claude Code as the pipeline brain: the main Claude Code session controls stage transitions, calls a sub-agent for RTL generation, and handles errors and rollbacks.

Differences from the full VeriFlow-Agent:

• No LangGraph / LangChain / Streamlit
• No pip install required
• Claude Code itself is the interaction and decision layer
• State persisted to JSON, recoverable after session restart

Architecture

User types /vf-rtl <project_dir>
     ↓
Main Claude (skill prompt injected)
     │
     ├→ Step 0: init + clarification → eda_env.sh, clarifications.md
     ├→ Stage 1: spec_golden  (vf-spec-golden merged agent)
     │            → spec.json + golden_model.py
     ├→ Stage 2: codegen      (vf-coder AI assembly per module, parallel)
     │            → rtl/*.v
     ├→ Stage 3: verify_fix   (inline sim + error recovery, 3-retry budget)
     │            → logs/sim.log, expected_trace_*.md, VCD analysis
     └→ Stage 4: lint_synth   (vf-linter + vf-synthesizer, parallel)
                  → logs/lint.log + synth_report.txt

4 stages: spec_golden → codegen → verify_fix → lint_synth. Sub-agents handle specialist work (RTL coding, lint, synthesis). Main session handles orchestration and error recovery.

Quick Start

1. Install from Source

git clone https://github.com/bjwanneng/veriflow-cc.git
cd veriflow-cc
python install.py

Installs to ~/.claude/:

• skills/vf-rtl/SKILL.md — Pipeline orchestration skill
• skills/vf-rtl/state.py — State management
• skills/vf-rtl/vcd2table.py — VCD waveform analysis
• skills/vf-rtl/coding_style.md — Verilog coding style rules
• skills/vf-rtl/cocotb_runner.py — Cocotb simulation runner
• skills/vf-rtl/iverilog_runner.py — Pure-Verilog simulation runner
• skills/vf-rtl/timing_contract_checker.py — Timing contract validator
• skills/vf-rtl/benchmark_runner.py — Batch evaluation & reporting
• skills/vf-rtl/bug_pattern_match.py — Automated divergence pattern matching
• skills/vf-rtl/corner_case_generator.py — Boundary test vector generation
• skills/vf-rtl/formal_property_gen.py — Assertion generation from timing contracts
• skills/vf-rtl/design_graph.py — Module connectivity graph analysis
• skills/vf-rtl/cross_verify.py — Dual-RTL equivalence comparison
• skills/vf-rtl/knowledge_base.py — Cross-project bug pattern learning
• agents/vf-coder.md — RTL code generation sub-agent
• agents/vf-spec-golden.md — Spec + golden model generation sub-agent
• agents/vf-tb-gen.md — Testbench generation sub-agent
• agents/vf-linter.md — Lint sub-agent
• agents/vf-synthesizer.md — Synthesis sub-agent

Uninstall: python install.py --uninstall

2. Prepare Project Directory

my_alu/
├── requirement.md        # Functional requirements (required)
├── constraints.md        # Design constraints (optional)
├── design_intent.md      # Preliminary design ideas (optional)
└── context/              # Reference materials (optional)
    └── reference.md

Input files:

If optional files are missing, the pipeline asks targeted clarification questions during Step 0.

3. Run in Claude Code

/vf-rtl /path/to/my_alu

Optional flags:

• --benchmark — After the pipeline completes, automatically run benchmark_runner.py and generate a JSON report at logs/benchmark_report.json.

Example:

/vf-rtl /path/to/my_alu --benchmark

Pipeline Stages

Strict sequential execution, no skipping:

spec_golden → codegen → verify_fix → lint_synth
     1            2          3            4

Key Features

Golden Model (golden_model.py)

Stage 1 produces golden_model.py which serves as both reference model and test vector generator:

• Algorithm implementation with cycle-accurate trace output
• Test vectors validated against spec.json timing contracts
• Used by vcd2table.py for waveform diff during error recovery

Inline Verilog Mini-Patterns

The vf-coder sub-agent includes 5 inline Verilog-2005 mini-patterns:

• FSM (three-block: state-reg + next-state + outputs)
• Hash round (single-cycle registered)
• Pipeline register (2-stage with valid passthrough)
• Handshake (hold_until_ack)
• Barrel shifter (variable-distance rotation, Verilog-2005 legal)

These give the LLM concrete register-transfer skeletons to adapt, eliminating the need for external reference implementations.

Common Pitfalls + Pre-Write Self-Check

vf-coder.md includes 7 common pitfalls (P1–P7) from SM3 retrospective:

1. Combinational latches from incomplete always @*
2. valid pulse cleared one cycle too early
3. Missing default in FSM case
4. Counter rollover via implicit overflow
5. valid and data updated in different cycles
6. Using _next value as if it were a register
7. Reset polarity mix-up

Mandatory 7-point pre-write self-check ensures every module is verified before writing.

Readiness Check Gate

Before proceeding past Stage 1, a readiness check validates spec.json and golden_model.py for completeness.

Persistent EDA Environment

EDA tool paths (iverilog, vvp, yosys) are discovered once in Step 0 and saved to .veriflow/eda_env.sh. Every subsequent EDA command sources this file, avoiding the "PATH doesn't persist between Bash calls" issue. eda_env.sh also exports PYTHONPATH pointing at the installed skill directory, so helper scripts can import state.py without per-call PYTHONPATH prefixes.

Structured Logging

All EDA outputs are saved to log files for post-run analysis:

• logs/lint.log — iverilog syntax check output
• logs/sim.log — integration simulation output
• logs/sim.raw.log — raw simulation output (iverilog_runner --save-raw-log)
• logs/wave_diff.txt — VCD vs golden model comparison
• logs/wave_table.txt — VCD waveform cycle table
• logs/expected_trace_golden.md — per-cycle register traces from golden_model.py (Stage 3 error recovery)
• logs/timing_diagnostic.json — bug classification + fix suggestions
• logs/prev_failure_summary.md — concise failure summary injected to next vf-coder retry
• workspace/synth/synth_report.txt — yosys synthesis report

Sim Hook Verification

The simulation hook uses strict 3-layer verification on logs/sim.log:

1. File must exist and be non-empty
2. No lines matching [FAIL] or FAILED: prefix
3. Must contain an explicit ALL TESTS PASSED summary line

This prevents false-positive "all green" when sim.log contains both passing and failing tests, or is empty.

Cocotb-First Integration Simulation

Stage 3 (verify_fix) uses cocotb (Python co-simulation) as the primary simulation path when available:

• cocotb's await RisingEdge(dut.clk) fires via VPI callback AFTER the NBA region, eliminating all Verilog TB-DUT race conditions
• Per-cycle internal register comparison against golden model trace
• Cycle-level timing contract assertions (registered output stability, pipeline delay)
• Falls back to Verilog $display-based testbenches when cocotb is unavailable

Failure Feedback Loop

When simulation fails:

1. timing_diagnostic.py classifies the bug (A=computation, B=timing offset, D=initialization)
2. A concise prev_failure_summary.md is built with cycle, signal, expected, actual, and fix suggestion
3. This summary is injected into the next vf-coder retry via PREV_FAILURE field
4. The retry addresses the exact divergence before any other rewriting

Interface Lock

spec.json port definitions are locked after Stage 1. Port semantic fields enforce consistent interpretation across all stages:

• reset_polarity: "active_high" only (reset ports must declare this)
• handshake: "hold_until_ack" | "single_cycle" | "pulse" (valid ports must declare this)
• ack_port: name of the associated ack input (required for hold_until_ack)

Timing Contracts

spec.json includes machine-verifiable timing contracts for every inter-module connection:

• producer_cycle, visible_cycle, consumer_cycle — exact cycle relationships
• same_cycle_visible, pipeline_delay_cycles — registered vs combinational semantics
• sample_phase — posedge or negedge sampling, preventing TB/DUT races

Error Recovery

• Structured Root Cause Analysis: Before modifying any file, must complete a 5-point analysis (error location → signal trace → root cause hypothesis → minimal fix plan → impact scope) written to stage_journal.md
• Golden model comparison: Run golden model with failing test inputs and compare intermediate values with RTL output
• Per-cycle trace diff: logs/expected_trace_golden.md (from golden_model.py) vs VCD-derived actual values — the fastest way to localise the wrong NBA assignment
• Failure feedback injection: prev_failure_summary.md is passed to next vf-coder retry targeting the exact divergence
• 3-retry budget: Stops after 3 failed fix attempts and asks user for help
• File control: No new .v files during error recovery; debug artifacts cleaned up after each attempt
• Testbench rule: TB infrastructure bugs may be fixed; assertions must not be weakened

Yosys Equivalence Check (Stage 4 hard gate)

After synthesis, yosys_equiv.py proves functional equivalence between the original RTL and the synthesized netlist using SAT-based induction (equiv_make → equiv_simple → equiv_induct). If equivalence is not proved, the pipeline marks lint_synth as FAILED and aborts.

Automated Bug Pattern Matching

bug_pattern_match.py catalogs 15 known bug patterns (6 from SM3 retrospective, 8 from later projects, 1 tooling). On simulation failure, it automatically matches the divergence signature against the catalog and reports confidence-ranked suggestions. Each pattern includes: symptom, root cause, fix, and prevention rule.

Coverage Measurement

iverilog_runner.py automatically computes test vector coverage ratio (exercised / total) by comparing the golden model's TEST_VECTORS against the simulation log. Reported in JSON output under coverage.*.

Corner-case Test Generation

corner_case_generator.py auto-generates 8 boundary-condition test vectors from spec.json ports: all-zeros, all-ones, min, max, alternating, LSB-hot, MSB-hot, half-range. Integrated into vf-tb-gen Step 5b as a mandatory supplement to golden model vectors.

Formal Property Generation

formal_property_gen.py generates Verilog-2005 compatible assertion comments from spec.json timing contracts, handshake protocols, and FSM state tables. Outputs a synthesizable assertion module for Yosys formal flows.

Design Graph Validation

design_graph.py builds a directed graph from module_connectivity and checks for:

• Combinational cycles (blocks Stage 1)
• Unreachable modules from top (blocks Stage 1)
• Fanout skew violations

Benchmark Runner

benchmark_runner.py supports batch evaluation, LLM variant comparison, and RealBench JSONL conversion. Outputs JSON/CSV/Markdown reports with per-stage pass/fail breakdown.

Cross-project Knowledge Base

knowledge_base.py persists bug pattern frequencies, design templates, and project outcomes to ~/.claude/skills/vf-rtl/knowledge/. Enables institutional learning: frequently-hit patterns are prioritized in agent prompts.

Standalone Tools

Project Output Structure

my_project/
├── requirement.md               # Functional requirements (required)
├── constraints.md               # Timing, area, power, IO constraints (optional)
├── design_intent.md             # Architecture preferences, IP reuse (optional)
├── context/                     # Reference materials (optional)
├── .veriflow/
│   ├── pipeline_state.json      # Pipeline state (resumable)
│   └── eda_env.sh               # EDA tool paths + PYTHONPATH (auto-generated)
├── logs/
│   ├── lint.log                 # iverilog lint output
│   ├── sim.log                  # Integration simulation output
│   ├── sim.raw.log              # Raw simulation log
│   ├── wave_diff.txt            # VCD vs golden model comparison
│   ├── wave_table.txt           # VCD waveform cycle table
│   ├── expected_trace_golden.md # Per-cycle register traces from golden_model.py
│   ├── timing_diagnostic.json   # Bug classification + fix suggestions
│   └── prev_failure_summary.md  # Concise failure summary for retry
└── workspace/
    ├── docs/
    │   ├── spec.json            # Interface spec (ports, constraints, timing contracts)
    │   └── golden_model.py      # Reference model with cycle-accurate trace
    ├── rtl/                     # Generated Verilog files
    ├── tb/                      # Testbenches (one per module + integration)
    ├── sim/                     # Compiled simulation (.vvp files)
    └── synth/
        └── synth_report.txt     # Yosys synthesis report

File Structure (Source)

veriflow-cc/
├── src/
│   ├── claude_skills/
│   │   └── vf-rtl/
│   │       ├── SKILL.md           # Pipeline orchestration skill
│   │       ├── state.py           # State machine (JSON persistence)
│   │       ├── init.py            # Project init (discovers EDA, writes eda_env.sh)
│   │       ├── vcd2table.py       # VCD waveform to cycle table converter
│   │       ├── iverilog_runner.py # Pure-Verilog simulation runner
│   │       ├── cocotb_runner.py   # Cocotb simulation runner
│   │       ├── timing_diagnostic.py  # Bug classification + fix suggestions
│   │       ├── timing_contract_checker.py
│   │       ├── benchmark_runner.py   # Batch evaluation & reporting
│   │       ├── bug_pattern_match.py  # Automated divergence pattern matching
│   │       ├── corner_case_generator.py  # Boundary test vector generation
│   │       ├── formal_property_gen.py    # Assertion generation
│   │       ├── design_graph.py       # Module connectivity graph analysis
│   │       ├── cross_verify.py       # Dual-RTL equivalence comparison
│   │       ├── knowledge_base.py     # Cross-project bug pattern learning
│   │       ├── error_recovery.md  # Stage 3 error recovery procedure
│   │       ├── design_rules.md    # Design rules for all stages
│   │       ├── coding_style.md    # Verilog-2005 coding rules
│   │       └── templates/         # Template files for sub-agents
│   │           ├── spec_template.json
│   │           ├── golden_model_template.py
│   │           ├── cocotb_template.py
│   │           └── tb_integration_template.v
│   └── claude_agents/
│       ├── vf-spec-golden.md      # Spec + golden model generation (Stage 1)
│       ├── vf-coder.md            # RTL code generation (Stage 2)
│       ├── vf-tb-gen.md           # Testbench generation
│       ├── vf-linter.md           # Lint sub-agent (Stage 4)
│       └── vf-synthesizer.md      # Synthesis sub-agent (Stage 4)
├── install.py                     # Python installer (symlinks to ~/.claude/)
├── tests/                         # Test suite (pytest + unittest)
├── CLAUDE.md                      # Claude Code project instructions
└── README.md                      # This file

Dependencies

• Python 3.10+ (for state.py, no pip packages)
• Claude Code (logged in)
• iverilog / vvp (optional, for lint/sim stages)
• yosys (optional, for synth stage)

No pip install required.

Tests

Run all tests:

python -m pytest tests/ -q

Or with unittest:

python -m unittest discover tests -v

Uninstall

python install.py --uninstall

Troubleshooting

Sub-agent returns "0 tool uses"

Ensure the agent's tools field uses comma-separated capitalized names:

# WRONG — causes silent tool permission failure
tools:
  - read
  - write

# CORRECT
tools: Read, Write, Glob, Grep, Bash

See GitHub Issue #12392 for details.

iverilog returns exit code 127

iverilog needs its internal drivers (ivlpp, ivl) which live in lib/ivl/. The pipeline auto-discovers and saves these paths. Verify with:

source .veriflow/eda_env.sh && iverilog -V

Simulation passes but pipeline reports FAIL

The sim hook uses strict 3-layer verification: (1) sim.log must be non-empty, (2) no [FAIL] or FAILED: lines, (3) must contain ALL TESTS PASSED. If your testbench prints [FAIL] in passing messages (e.g., "checking FAIL case"), use a different format to avoid triggering Layer 2.

Contact

Add WeChat for more details and discussion:

Email:bjzhangwn@gmail.com
